DPJ-100 Single Layer Roll Feeding Cup Lid Forming Machine
DPJ-145 Single Layer Roll Feeding Bowl Lid Forming Machine
DPJ-200 Single Layer Roll Feeding Super Bowl Lid Forming Machine
The mold is clamped by pressing plate, which is convenient for adjustment and installation.The molding station is equipped with positive and negative pressure devices.
The single-layer paper cover forming machine series equipment adopts advanced forming technology, which has the advantages of simple operation, easy mold replacement, stable performance, high efficiency, environmental protection and energy saving. According to the different requirements of customers, it adopts automatic roll paper feeding and paper sheet feeding, creasing, embossing, punching, feeding to the mold, heating, crease, knurling, forming and other series of automatic functions. The same mold can achieve different design requirements on the top of the lid by changing the indentation version.
The main motor of the cup lid forming machine adopts frequency conversion speed regulation: the number of punching times can be adjusted from 10 to 20 times per minute, and the appropriate number of punching times can be set according to the length of the stroke and the difficulty of forming.
Technical Parameters
Customs code: 8441309000
Paper cover specifications:
height (8-15) mm, DPJ-100/S100 diameter (60 -100) mm, speed: (70-100) pieces per minute.
Height (8-15) mm, DPJ-145/S145 straight strength (100-140) speed: (60-75) per minute.
Height (8-15) mm, DPJ-200/S200 diameter (140 -200) mm, speed: (45-60) pieces/min
Applicable paper: single and double PE/PLA coated paper, coated paper, glazing coated paper (250-480g/m2)
Power: 10kw
Power supply: AC380V 3-phase, 50Hz (can be customized according to customers)
Working air source: air consumption 0.02 cubic meters per minute, working air pressure 0.3MPa
The total weight of the equipment: Cup lid machine .2100KG.
Bowl cover machine.2500KG.
Giant bowl machine 3300KG.
Cup lid machine packaging size 1920*1640*2000
Bowl cover machine packaging size 2200*1880*2100
Giant bowl lid machine packaging size 2600*1850*2200
